FT 1020 LB/H GEN 2 INJECTOR
FT 1020 LB/H GEN 2 INJECTOR
SKU:5010114197
Couldn't load pickup availability
Share
Contact us to see if the product is available
The 1020 lb/h (10,710 cc/min @ 90 psi) FT Injector is the absolute benchmark for extreme racing applications in the FT Injector family. It is a low-impedance injector (1.5 Ohm) that requires the use of a Peak & Hold driver, such as the 8A/2A model or the Peak & Hold PRO. FT injectors are compatible with any ECU and all fuel types (gasoline, ethanol, alcohol/methanol, nitromethane, nitropropane, MTBE, and ETBE). They feature EV1 connectors with silver-plated terminals for superior conductivity and corrosion-resistant internal components.
The GEN 2 has been designed to meet the needs of ultra-high-power engines, ensuring the flow rate required for peak performance under any conditions.
PRODUCT FEATURES
- Ultra-High Flow Rate: Designed for extreme power, it offers one of the highest flow rates on the market. Ideal for turbocharged engines with high boost levels.
- Precision Engineering: Each injector is crafted to ensure precise delivery, maintaining optimal air-fuel ratios and maximizing combustion efficiency while resisting restrictions caused by fuel contaminants.
- Versatile Compatibility: Usable with all ECUs and a wide range of fuels (Gasoline, Ethanol, Methanol, Nitromethane, etc.).
- Reliable Connectors: Standard EV1 with silver-plated terminals for improved conductivity and secure locking, even in the presence of strong engine vibrations.
-
Redesigned for Durability: Built from hardened steel with a single moving part, the plunger, to reduce failure points and ensure consistent performance in the harshest environments.
TECHNICAL DESCRIPTION
- Low impedance: 1.5 Ohm.
- Driver requirement: Use of an 8A/2A Peak and Hold driver is required.
- Voltage limit: up to 24V.
-
Protection rating: IP67 / NEMA6.
DIMENSIONS AND WEIGHT
- Injector: 86.3 x 29 mm.
- Weight: 160 g.
-
Packaging: 223 x 162 x 60 mm.
BOX CONTENTS
- 1 FT GEN 2 Injector.
- 1 User manual.
Warranty: 90 days
WARNING
All GMC Racing items that result in power increases exceeding those permitted by the road traffic laws of the user's country are intended exclusively for competitive use.
GMC Racing declines any responsibility for any use of the product contrary to national regulations.
